3D assembly videos of drive systems

Motors, gears, clutches explained as a 3D animation

Go berserk? Not with the Animations-Maschine! As a customer order, for the company ATLANTA Antriebssysteme E. Seidenspinner GmbH & Co. KG the Animations-Maschine produced several assembly videos on the subject of drive technology, motors, gears and clutches. How does the correct and precise power transmission between the engine and the gearbox succeed? How can a rack be adjusted as precisely as possible? The assembly videos explain exactly these questions step by step and show customers from the industrial environment and mechanical engineering what needs to be considered during assembly.

Example - assembly video of racks

The 3D assembly video for assembling racks starts with a list of the tools required. Then two racks are connected and precisely aligned with the help of measuring rollers and a measuring bridge so that the distances between the teeth match. The video should be simple and appealing. For this reason, the products were visualized in a white empty room. Disturbing elements that distract from the actual assembly are therefore not available.

Implementation of video production - 2017

3D assembly videos replace videos that were actually shot

Before the creation of the 3D animation videos, there were already real videos of the various drive systems. However, they were already about 10 years old and are therefore getting on in years. These videos were used as a default and the videos that were actually shot should be converted into appealing 3D animations.

Old real video becomes new 3D animation

Old real video becomes new 3D animation

Example - assembly video of a coupling for a servo gearbox of the type HT & HP

This video also begins by listing the parts and tools required. The coupling is then placed on the motor flange and fastened with a torque wrench. After checking the concentricity of the connecting coupling with the aid of a dial gauge, the motor is connected to the gearbox.

Implementation of video production - 2017

Free initial consultation

Are you looking for a 3D agency that also explains your technical product with a 3D assembly video? But you don't yet know whether this will work for you and your product? The Animations-Maschine offers you a free initial consultation. Let's just talk about your product and project. Together we will work out an ideal solution for your project. You then decide in your own time whether you want to finally have a 3D animation or an assembly video produced.

Arrange an initial consultation now

Example - assembly video of an assembly of a motor flange

The 3D assembly video for assembling a motor flange shows the important assembly steps. The contact surfaces of the motor flange and gearbox must be cleaned before assembly. Only then can the two components be connected and screwed tight.

Implementation of video production - 2017

Example - assembly video of a coupling for an E & B type servo gearbox

Before the coupling is attached to the motor flange, the appropriate installation dimension must be taken from the product catalog. After checking the concentricity of the connecting coupling with the aid of a dial gauge, the motor is connected to the gearbox.

Implementation of video production - 2017

Gallery of 3D animations of drive systems

A small excerpt from implemented animations from the area of engines and transmissions.

Matching 3D product visualizations of drive systems

A 3D product visualization was also created for each gearbox and engine.
Further information can be found in the section 3D procuct visualization of gears and motors.

Matching 3D product visualizations of gears and motors

Matching 3D product visualizations of gears and motors

Let create your own professionally 3D assembly video

Do you also have products from the field of drive systems, drive technology, motors, gears or couplings or generally interesting technical products? If you want to have your products explained and are looking for a 3D animation agency, then I am your partner and will be happy to help you. Contact me and together we will create a suitable animation video, mounting video or assembly animation for your purpose. Precisely tailored to your products and requirements.

Contact now
Testimonial Atlanta

Robert Adamietz, Marketing Manager
ATLANTA Antriebssysteme E. Seidenspinner GmbH & Co. KG

Very competent and quick to implement!

"In the case of products that require explanation, it is important to show the customer how they work in a simple and understandable manner. Assembly videos that we shot ourselves in the past take up a lot of manpower and time that is no longer available today. We found the alternative with the Animations-Maschine. In the meantime we have switched all assembly videos to animation videos and will continue to do so in the future. Individual conception, top advice and timely implementation of the various projects make Animations-Maschine a reliable partner with whom we are very happy to work. Many thanks to Mr. Walgenbach for the work done."
