3D mounting videos of a doorbell and a house number

Executed step by step as a 3D animation

The Animations-Maschine rings the bell! As a customer order, the Animations-Maschine created a total of 9 assembly videos for different assembly variants of a doorbell and a house number for the Türklingel-Shop. The 3D animation videos have been produced for customers in the field of house construction and facade technology.

Example - mounting video of a surface-mounted doorbell

This video shows the installation of a surface-mounted doorbell, which can be mounted directly on the wall and offers enough space for the wiring. The mounting video begins with a representation of a house wall from which four wire lines for the doorbell switch lead. 2 wires for the bell switch and two for the LED ring lighting. After installing the wires, two holes are drilled in the wall and two dowels are inserted. The housing is then screwed onto the wall and wired to the bell cover.

Implementation of video production - 2021

High quality 3D mounting videos

The Türklingel-Shop company wanted to have professional installation videos produced, which are of high quality and attractively designed and which reflect the elegant look of the stainless steel doorbell. Distracting house facades were deliberately avoided. Instead, a neutral concrete wall was used uniformly, which represents the house wall in exposed concrete optics.

Example - mounting video of a doorbell with drill holes

This video shows the mounting of a bell plate, which is attached to the house wall with drill holes with 4 screws. The mounting video begins with a representation of a house wall from which two wires lead for the bell switch. Boreholes are marked, drilled and each provided with a dowel. After installing the wires, the stainless steel plate is screwed onto the house wall.

Implementation of video production - 2019

Different mounting variants implemented as a separate video

The same doorbell is available in different product versions. Depending on the surface or installation preference, the doorbells can be glued, screwed on or clamped. Since there is a separate product for each type of installation in the online shop, a separate installation video was also created. The appropriate mounting video is thus linked directly in the respective item description.

Example - mounting video of a doorbell with fastening claw

A second installation variant shows installation with fastening claws in a flush-mounted box. To do this, the fastening claws are bent up and clamped in the flush-mounted box.

Implementation of video production - 2019

Example - mounting video of a doorbell with threaded pins

In this third installation variant, the bell plate is attached to the house wall with the help of threaded pins. Threaded pins are screwed into the eyes of the bell plate and pressed into dowels.

Implementation of video production - 2019

Example - mounting video of a doorbell with fastening silicone

This video shows the mounting of a bell plate which is glued on with fastening silicone. After installing the wires, the stainless steel plate is glued to the house wall with silicone. This installation variant is always used when no drill holes can be made in the wall.

Implementation of video production - 2019

Example - mounting video of a doorbell with a bolt plate

Similar to the previous mounting videos, the mounting of a doorbell plate is also shown here. However, the bell plate is inserted into two dowels with the help of a bolt plate. The bell plate can then be easily aligned.

Implementation of video production - 2019

Consulting for 3D assembly videos

Free initial consultation

Are you looking for a 3D agency that also explains your technical product with a 3D assembly video? But you don't yet know whether this will work for you and your product? The Animations-Maschine offers you a free initial consultation. Let's just talk about your product and project. Together we will work out an ideal solution for your project. You then decide in your own time whether you want to finally have a 3D animation or an assembly video produced.

Arrange an initial consultation now

Example - mounting video of a house number with fixing silicone

After the videos for the doorbells were so well received by the customers, mounting videos for assembling a house number were created in the same way. The first mounting video shows the assembly of a house number which is glued on with fixing silicone. The mounting video begins with a representation of a house wall to which the stainless steel house number is glued with silicone. This installation variant is always used when no drill holes can be made in the wall.

Implementation of video production - 2019

Example - mounting video of a house number with threaded pins

This video shows the mounting of a house number which is attached to a house wall with threaded pins. The mounting video begins by screwing the threaded pins into the house number. With the tips of the threaded pins, marking holes are pressed into the house wall, which are necessary for the correct positioning of the holes. At the end, the house number is inserted into the dowels with the threaded pins.

Implementation of video production - 2019

Example - mounting video of a house number with tape

This video shows the mounting of a house number which is stuck on with double-sided adhesive tape. The mounting video begins by peeling off the protective film from the double-sided adhesive tape. This is then used to glue the stainless steel house number to the house wall.

Implementation of video production - 2019

Gallery of 3D animations of doorbells and house numbers

A small excerpt from implemented animations from the field of house and facade design.

Mounting instructions as a printed version

Just as important as the animated mounting videos, it was right from the start that, in the second step, individual images could be created for printed mounting instructions. All mounting variants should each be summarized in a PDF as illustrated mounting instructions. Further information can be found in the section 3D mounting instructions of a doorbell and a house number.

3D mounting instructions of a doorbell and a house number

Let create your own professionally 3D assembly video

Do you also have products from the field of house construction, house facades, installation technology or generally interesting technical products? If you want to have your products explained and are looking for a 3D animation agency, then I am your partner and will be happy to help you. Contact me and together we will create a suitable animation video, mounting video or assembly animation for your purpose. Precisely tailored to your products and requirements.

Contact now

Services rendered in creating the assembly video

  • 3D animation services - CAD construction

    CAD construction

  • 3D animation services - CAD model creation

    CAD model creation

  • 3D animation services - Texturing

    Texturing

  • 3D Animation Leistung - Animation creation

    Animation creation

  • 3D animation services - Rendering

    Rendering

  • 3D animation services - Text overlays

    Text overlays

  • 3D animation services - Music integration

    Music integration

  • 3D animation services - Post production

    Post production

  • 3D animation services - Provision in various video formats

    Provision in various video formats
