3D product visualizations from CAD data

From 3D model to photorealistic rendering

The Animations-Maschine produces smut. You heard that right, but not so wild. Several photorealistic 3D product renderings were created for an online shop that offers feeding bowls, feeding machines and accessories for pig fattening and poultry farms. And that directly from existing 3D models of the CAD constructions.

Gallery of feeding bowls

Around 50 different feed bowls for poultry farming were visualized as 3D renderings in several versions, sizes and designs. Some feed bowls are equipped with sensors to check whether enough feed has been refilled.

Rendering from CAD data

For the 3D product visualization of the various items, the customer provided the CAD data in a common exchange format. These could be imported directly into the 3D visualization program and provided with the appropriate materials and rendered.

This workflow is very effective and straightforward. Products do not have to be transported to the photo studio and then stored again afterwards. Especially with the feeding machines, which are as big as a washing machine, manual product photography would be very time-consuming.

3D rendering from CAD data

Gallery of feed containers

For pig breeding, certain feed containers are filled with dry feed or pellets and provide the pigs with the feed they need. These 3D product visualizations mainly used 3D materials made of stainless steel or metal.

Consulting for 3D product visualizations

Free initial consultation for your 3D product visualizations

Are you also looking for a 3D agency that also presents your products and articles with a 3D product visualization? But you don't know yet whether this will work for you and your articles? The Animations-Maschine offers you a free initial consultation. Let's just talk about your product and project. Together we will work out an ideal solution for your project. You then decide at your leisure whether you ultimately want to have a 3D visualization or a 3D product rendering produced.

Arrange an initial consultation now

One lighting setup for all renderings

At the beginning, a lighting concept was created and coordinated with the customer. This effort was incurred only once at the start of the project and could be used again for each subsequent product rendering. Once the effort has been made, it can often be used again for 3D renderings.

The customer wish was to create a slightly subtle and soft shadow. This shadow should also be rendered on its own layer. Thus, the product images should be able to be used with and without shadows. Thanks to 3D visualization, this is possible directly from the program. The products are on one level and the shadows on another level. This means that no manual cropping of the product images is necessary.

Lighting setup 3d renderings

Lighting setup 3d renderings

Gallery of automatic feeders

An automatic supply of feed is ensured via automatic feeders. Some of the products are 2 meters high. But thanks to 3D product visualization, it doesn't matter how big or unwieldy the products are. All sizes can be professionally rendered with the same manageable effort.

Materials and textures once defined

Just like the right lighting setup, the common materials were defined at the start of the project. Most of the products are always made of the same orange or blue plastic. Larger machines are made of galvanized sheet steel or stainless steel.

The set, once created from the various materials, could therefore be used again and again and all products look as if they were made of one piece.

3D materials and textures for product renderings

3D materials and textures for product renderings

Gallery of other animal husbandry products

More individual products related to animal husbandry, breeding and agriculture were also visualized as 3D renderings for the online shop.

Let create 3D product visualizations professionally

Do you also have products and articles that you want to market and for which you need product images? If you want to have 3D product rendering of your products and are looking for a 3D visualization agency, then we are your partner and will be happy to help you. Contact us and together we will create a suitable 3D visualization, product image or illustration for your application. Precisely tailored to your company, requirements and corporate design.

Contact now

Services rendered in creating the 3D product visualizations

  • 3D visualizations services - CAD data import

    CAD data import

  • 3D visualizations services - Texturing


  • 3D visualizations services - 3D visualization

    3D visualization

  • 3D visualizations services - Rendering


  • 3D visualizations services - Composition


  • 3D visualizations services - Provision in various picture formats

    Provision in various picture formats
