3D assembly videos of mounting systems for roof constructions

Securants and solar systems simply mounted

Wittenauer GmbH is a specialist for roof and facade construction and has developed its own mounting system for elevated roof structures. This mounting system can be used for a trapezoidal sheet metal, concrete or wooden roof and offers attachment points of superstructure roofs, as well as mounting options for solar systems, air conditioning units, walkway gratings or even radio masts.
How easy the mounting is step by step, the Animations-Maschine explains with the help of 3D animated mounting videos.

3D assembly video mounting system for elevated roof construction

To explain the assembly of this special elevated mounting system, the beginning of the video shows how the mounting pipe is screwed onto the trapezoidal sheet of a flat roof through the bitumen sheet with the help of a bracket. Insulation and foils are then laid and supporting structures are screwed on via brackets, in order to attach solar systems or air-conditioning units to the roof in this way. As a further animation, the installation of an aluminum panel facade system was explained in the 3D video.
It sounds complicated, but it can be so simple.

Realization video production - 2021

From illustrated storyboard to finished assembly video

At the beginning of the animation creation there is always an agreement with the customer. What should be shown and how? Which assembly steps are important? What should be explained and visualized in detail? All these questions are included in an initial rough description of the process. Based on this, an illustrated storyboard is then created. In this storyboard, all important assembly steps are already depicted as they will be seen in the later animation. You as the customer can therefore see in advance what the later video will look like and, if necessary, incorporate any correction requests.

Storyboard-assembly-video-mounting-system-Roof-PIN-A.pdf

Example storyboard 3D assembly video mounting system for elevated roof construction

Integration of photos into 3D animation

The customer wanted to integrate real photos of one of his reference objects into the 3D assembly video. In the reference object, special aluminum frames were installed on a design roof with a honeycomb structure. There was even a 3D model of the elaborate roof construction, which could be imported and used in the animation. After the assembly is explained, the camera is guided exactly into the viewing angle of the first real photograph and the real pictures are faded in one after the other by cross-fades at the end of the video.

Transition from 3D model to photo

Free initial consultation for Your Custom 3D Assembly Animation

Are you looking for a 3D agency that also explains your technical product with a 3D assembly video? But you don't yet know whether this will work for you and your product? The Animation-Maschine offers you a free initial consultation. Let's just talk about your product and project. Together we will work out an ideal solution for your project. You then decide in your own time whether you want to finally have a 3D animation or an assembly video produced.

Arrange an initial consultation now

Image gallery of 3D animations of mounting systems for roof superstructures

A small excerpt of implemented animations from the area of mounting systems for solar installations on flat roofs.

3D installation video of fastening securants on a flat roof

This installation video is the second one from the same product group. Since the products are very similar, some animation steps could be taken over from the first video and reused with slight modifications. Which always has a positive effect on production costs. In this product variant, securants are mounted on a flat roof, which is intended to prevent people from falling during roof work. At the end of the installation video, it is shown how a steel cable runs through the safety barriers at the edge of the industrial hall, thus providing all-round secure support.
So important and guaranteed for safety.

Realization video production - 2021

3D visualizations for website

After the assembly videos were produced, further visualizations should be created, which should show the different roof assemblies. Possible mounting types are in trapezoidal sheet metal, in concrete roofs, or in wooden constructions. And that in each case once with bitumen sheeting and once with roof foil. Since the products as well as most of the 3D elements had already been created in the installation videos and were therefore already available, the 3D visualizations were produced quickly and, after rendering, were directly ready for integration into the website.

Have your own 3D assembly videos professionally created

Do you have products in the field of flat roofs, solar systems, securants, trapezoidal sheets or interesting technical products in general? Do you want to have your products explained and are looking for a 3D animation agency, then we are your partner and will be happy to help you. Contact us and together we will create suitable assembly videos or product videos for you. Exactly tailored to your needs and requirements.

Contact now

FAQ – Frequently Asked Questions About 3D Assembly Videos for Roof Construction Mounting Systems

Why are 3D assembly videos ideal for roof construction mounting systems?

Roof construction mounting systems often consist of numerous components that are installed in several layers above the roof structure. A 3D assembly video visualizes every installation step in the correct order and clearly shows how mounting pipes, brackets, insulation layers and support structures interact. This makes even complex roof assemblies easy to understand.

Can a 3D assembly video explain different roof types within the same project?

Yes. The same mounting system can often be installed on trapezoidal sheet metal roofs, concrete roofs or timber constructions. A 3D assembly video can illustrate these different installation scenarios and demonstrate how the mounting principle remains consistent across various roof structures.

How can manufacturers reduce production costs when creating multiple assembly videos for related products?

Once CAD models, textures and animation sequences have been created, many assets can be reused for similar products. This allows additional assembly videos for related mounting systems, safety devices or facade solutions to be produced more efficiently and at lower cost.

Can real project photos be integrated into a 3D assembly video?

Absolutely. 3D animations can seamlessly transition into real reference photos after the installation process has been explained. This combination helps viewers connect the technical assembly instructions with real-world applications and completed construction projects.

Why are 3D assembly videos useful for mounting systems used with solar installations and rooftop equipment?

Mounting systems for photovoltaic modules, air-conditioning units, walkway gratings and roof safety equipment are often hidden beneath the final installation. A 3D animation can reveal these concealed components and explain the complete structural concept in a way that traditional filming cannot achieve.
